ERA-TAC Picatinny rail for Sabatti Rover LA Opis proizvoda

Introduction

Picatinny rail consists of slots with 5.23 mm spaces between one another, which means that it can be used across its entire length. It is simple to mount and interchangeable – if something is made for a Picatinny rail, it will fit regardless of the manufacturer or manufacturing date. It is affordable, resilient and reliable – this is why it so commonly used by professionals and military. Because of all its great qualities, Picatinny rail has been dominating the rail market in the recent years.

Picatinny is a big step forward from the Weaver standard. Weaver has a few predesignated slots while Picatinny has slots all over its surface, allowing the device to be mounted wherever the user finds it fitting. Weaver's slot is 3.8 mm wide, which is why ring mounts made for a Weaver rail will also fit on a Picatinny rail while ring mounts made specifically for a Picatinny rail will not fit on a Weaver rail. This is one of the main reasons why Picatinny is a far better mounting solution.

Recknagel is currently the biggest manufacturer of mounts in Germany. Their Picatinny rails, known for great fit and finish, are mostly made of high-grade aluminum (a few are also made of steel), which is why they are very reliable. Screws are included. Currently, a common trend among rifle manufacturers is making receivers out of aluminum – mounting a Picatinny rail made of aluminum on one of those receivers is thus not problematic. Their products are marketed either under the name Recknagel or Era-Tac.

About the rifle

The Italian region of Val Trompia is known for its weapon craftsmanship history. The Sabatti family are among those credited for the region's reputation. Lodovico Sabatti, for example, was an excellent designer of flintlock pistols and barrels, while Giuseppe Sabatti made exceptional blunderbusses. Another Giuseppe Sabatti was one of the best gunsmiths in the world during the first half of the nineteenth century. In 1960, the sons of Antonio Sabatti started a business based on the manufacture of shotguns and rifles – it soon became a success. Since then, the Sabattis are continuing the tradition of their predecessors by constantly looking to satisfy the demands of firearms users around the world. Because so many members of this family excelled in weapon craftsmanship, Sabatti has remained a renowned and reputable company up to this day.

As regards action length, there are two versions of Sabatti Rover rifles – Sabatti Rover 600 rifles with a short receiver and Sabatti Rover 870 rifles with a short and long receiver. Both are bolt-action rifles. This mount is suitable for Sabatti Rover Model 870 (long action).

Model 870 is an updated version of Model 87. In contrast to Model 600, Model 870 is available in both short and long-action versions. Tthe rifle is chambered for: 5.6x57, 6x62 Frères, .243 Win., 6.5x55 SE, 6.5x57, 6.5x55 RWS, .270 Win., 7x57, .308 Win., .30-06 Sprg., 8x57 and 9.3x62. The fixed magazine holds a max. of 5 cartridges. For mounting purposes, there are two holes on the front side of the receiver and two holes on the rear side of the receiver, 4 holes altogether.

Sabatti Rover rifles are available in two action lengths. When a rifle is available in more than one action length, only two-piece mounts are interchangeable between these rifles – a two-piece mount made for Sabatti Rover 870 (long action) can also be mounted on Sabatti Rover 600 (short action). One-piece mounts will only fit a rifle with a specific action length – a one-piece mount made for Sabatti Rover 870 (long action) will not fit Sabatti Rover 600 (short action).

Mounting details

A: 21.9 mm
B: 102.7 mm
C: 15.3 mm
BHU: 3.2 mm
Fi: 6-48
R1: R17
R2: R60

Mounting instructions

Remove all the stains (grease, oil etc.) from the rifle's receiver with a cleaning fluid (acetone). Once the surface is clean and dry, check whether the screws match the rail and the holes on the receiver. Make sure that the Picatinny rail is compatible with the rifle by inspecting the mounting holes on both. Before mounting the rail permanently, apply a minimal amount of thread-locking fluid 278 or 648 on screws and contact surfaces. Be careful not to get the fluid in or near the mounting holes. Carefully clean the remaining excess fluid around the rail with a cleaning fluid. Using a torque driver, screw the screws appropriately (up to 2.2 Nm) – do not overtighten.

Warranty

The product has a warranty period of 10 years.

Opća svojstva

Proizvođač ERA-TAC
Serija montaže ERA-TAC Picatinny Rails
Izrađeno u Njemačka
Jamstvo 10 godina
SKU 57050-0175

Fizička svojstva

Vrsta nišanskog uređaja Picatinny Rail
Materijal Aluminij
Boja Crna
Dužina 148.00 mm
BH visina. 6.50 mm
Nagib nosača 0 MOA
A 21.9 mm
B 102.6 mm
C 15.4 mm

Characteristics

Suitable for Compatibility Above Picatinny Rail
Suitable for Compatibility Below Sabatti Rover 870, Sabatti Tactical LA, Sabatti Tactical EVO, Sabatti TLD, Sabatti pre-2017 Compact Scout LA, Sabatti Rover Traqueur
